Double Weather Compression Cable Gland

Double Weather Compression Cable Gland
Double Weather Compression Cable Gland
Product Code : DCCG 03
Brand Name : INDUSTRIAL PRODUCTS
Price And Quantity
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • - INR
Product Specifications
  • Conductor Type
  • Solid
  • Rated Temperature
  • Celsius (oC)
  • Conductor Shape
  • Other
  • Length
  • Meter (m)
  • Insulation Material
  • Other
  • Application
  • Industrial, Marine, Mining, Power Station, Railway
  • Conductor Material
  • Aluminum
  • Storage Temperature
  • Celsius (oC)
  • Dimension(L*W*H)
  • M20-M100
  • Warranty
  • 18 Months
Product Description

With having years of domain experience, we are reckoned as a prestigious  manufacturer and trader of Double Weather Compression Cable Gland. Specially designed for corrosive working environment utilization purpose, this Double Weather Compression Cable Gland has been fabricated from IS 319 grade brass. Also available with mild steel, stainless steel or aluminum made body, this type of cable gland is notable for its rust proof nickel plated finishing. We also use cadmium, tin or chrome based coating material to apply on this type of cable gland. The offered product consists of necessary parts like washer, check nut, neoprene made sealing ring, Armour clamping ring, gland cover and man  gland body.

Technical Specification :

Material

Brass(IS 319) -Standard. (In AL/Mild Steel/SS. also available)

Finish

Nickel plated-Standards. (Tin/Cadmium/Chrome also available)

Threads

ET"/BSC-Standards (PG/Metric/NPT/BSP also available)

Sealing Ring

Neoprene

Ref. Standard

IS / IEC 60529:2001

Protection Class

IP 66 as per IS / IEC 60529:2001

Type test no.

CIMFR/TC/P/H 434

Application

Generally for Outdoor / Indoor use for armoured & unarmoured Cable

Series Code

IPW

Check Nut

6

Armour Clamping Ring

Washer

7

Main Gland Body

Nipple Entry Part

8

Neoprene Outer Rubber

Neoprene Inner Rubber

9

Gland Cover.

Armour Clamping Cone



Suitable For Cable Overall Dia

Cosmos Code Ipw Series

A
DIA mm

B
DIA mm

C
(A/F) mm

D(A/D) mm

E Nipple Entry (ET/BSC)

F Length mm

From

To

6.0

12.5

IPW 01SS

13.0

12.5

21.0

24.0

3/4"

13.0

12.0

16.5

IPW 01S

18.0

14.5

25.0

29.0

3/4"

15.0

16.5

18.5

IPW 01

19.0

14.5

27.5

31.5

3/4"

15.0

16.5

18.5

IPW 01A

19.0

14.5

27.5

31.5

1"

15.0

18.5

20.0

IPW 02

21.0

18.0

30.0

34.5

1"

15.0

18.5

20.0

IPW 02A

21.0

14.5

30.0

34.5

3/4"

15.0

20.0

23.0

IPW 03

23.5

19.0

31.5

36.0

1"

15.0

23.0

26.0

IPW 04

27.0

20.5

36.0

41.5

1"

15.0

23.0

26.0

IPW 04A

27.0

22.0

36.0

41.5

1.1/4"

15.0

26.0

30.0

IPW 05

31.0

25.5

41.0

47.0

1.1/4"

15.0

26.0

30.0

IPW 05A

31.0

27.0

41.0

47.0

1.1/2"

15.0

30.0

33.0

IPW 06

34.5

31.0

47.0

54.0

1.1/2"

15.0

30.0

33.0

IPW 06A

34.5

27.0

47.0

54.0

1.1/4"

15.0

33.0

37.0

IPW 07

38.0

32.0

50.0

57.0

1.1/2"

15.0

37.0

41.0

IPW 08

42.5

38.5

56.0

64.0

2"

15.0

41.0

46.0

IPW 09

47.0

40.0

59.0

67.0

2"

15.0

46.0

52.0

IPW 010

53.0

44.0

67.0

77.0

2"

20.0

46.0

52.0

IPW 010A

53.0

48.0

67.0

77.0

2.1/2"

20.0

52.0

54.0

IPW 011S

57.0

51.00

74.0

85.0

2.1/2"

20.0

54.0

61.0

IPW 011

62.0

56.5

80.0

92.0

2.1/2"

20.0

61.0

66.0

IPW 012

68.0

64.0

85.0

98.0

3"

20.0

66.0

72.0

IPW 013A

73.0

67.0

90.0

103.0

3"

20.0

72.0

78.0

IPW 013

80.0

74.0

99.0

113.0

3.1/4"

20.0

78.0

84.0

IPW 014

85.0

78.0

105.0

121.0

3.1/2"

20.0

84.0

94.0

IPW 015

97.0

90.5

114.0

132.0

4"

20.0

94.0

104.0

IPW 016

106.0

101.0

130.0

149.0

4.1/2"

20.0
